FiberHome AN6001-G16 User Manual

5 Web-Based Configuration Guide
Deleting a Super VLAN or Sub VLAN
1. On the Bind Sub VLAN to Super VLAN tab, select the desired Super VLAN or
Sub VLAN entry and click Delete in the same row under the Operation column.
The Delete confirmation dialog box appears.
2. Click Yes in the dialog box to delete a Super VLAN or Sub VLAN entry.
5.8.45.8.4 ARP Proxy Switch on VLAN
This section introduces how to enable or disable the ARP proxy function of Super
VLAN through the Web GUI.
Planning Data
Item
Description Example
VLAN ID
Read only
123
ARP Proxy Switch (Router)
Enable or disable the cross-network segment ARP proxy
function.
Disable
ARP Proxy Switch (Inner Sub
VLAN)
Enable or disable the intra-VLAN ARP proxy function.
Disable
ARP Proxy Switch (Outer Sub
VLAN)
Enable or disable the inter-VLAN ARP proxy function.
Disable
Procedure
1. On the main screen, select Manage VLAN→ARP Proxy Switch On VLAN to
display the ARP Proxy Switch On VLAN tab.
2. On the ARP Proxy Switch On VLAN tab, set parameters of the ARP proxy
switch according to the planning data.
Version: A
65
