FiberHome AN6001-G16 User Manual

5 Web-Based Configuration Guide
2. After modifying the parameter(s), click Save.
Deleting a QinQ Profile
1. On the QinQ Profile tab, select the desired QinQ profile and click Delete in the
same row under the Operation column. The Delete confirmation dialog box
appears.
2. Click Yes in the dialog box to delete the QinQ profile.
5.7.25.7.2 OLT QinQ Domain
This section introduces how to create, modify and delete an OLT QinQ domain
through the Web GUI.
Planning Data
Item
Description Example
Domain Name
The name of the selective QinQ domain
hhh
Upstream
Rule Clause
Rule Type
Configure this item according to the network
planning of the operator.
Destination MAC
Address
Operator
Configure this item according to the network
planning of the operator.
Match If Present
Rule Value
Configure this item according to the network
planning of the operator.
00-00-00-00-00-00
Downstream
Rule Clause
Rule Type
Default Source MAC Address
Operator
Default Match If Present
Rule Value Default 00-00-00-00-00-00
Old_CVLAN
Low
Old_CVLAN Low The CVLAN ID transparently transmitted
100
Old_
CVLANCoslow
The priority of the CVLAN transparently transmitted.
Value range: 0-7. The value 7 indicates the highest
priority and 0 the lowest one.
0
Version: A
53
