Wireless ADSL Router User Manual
14
address if it is not in this format.
PPPoA/PPPoE Select this option if your ISP requires you to use a PPPoE connection.
This option is typically used for DSL services. Select Dynamic PPPoE to obtain an IP
address automatically for your PPPoE connection. Select Static PPPoE to use a static
IP address for your PPPoE connection. Please enter the information accordingly.
Bridge Mode The modem can be configured to act as a bridging device between your
LAN and your ISP. Bridges are devices that enable two or more networks to
communicate as if they are two segments of the same physical LAN. Please set the
Connection type
5.3.3. PPPoE/PPPoA
Select this option if your ISP requires you to use a PPPoE connection. This option is
typically used for DSL services. Select Dynamic PPPoE to obtain an IP address
automatically for your PPPoE connection. Select Static PPPoE to use a static IP
address for your PPPoE connection. Please enter the information accordingly.
Username Enter your username for your PPPoE/PPPoA connection.
Password Enter your password for your PPPoE/PPPoA connection
Encapsulation For both PPPoE/PPPoA connection, you need to specify the type of
Multiplexing, either LLC or VC Mux.
Connection Setting For PPPoE/PPPoA connection, you can select Always
on or Connect on-demand. Connect on demand is dependent on the traffic. If there
is no traffic (or Idle) for a pre-specified period of time), the connect will tear down
automatically. And once there is traffic send or receive, the connection will be
automatically on. Static/Dynamic IP Address For PPPoE/PPPoA connection, you
need to specify the public IP address for this ADSL Router. The IP address can be
either dynamically (via DHCP) or given IP address provide by your ISP. For Static IP,
you need to specify the IP address, Subnet Mask and Gateway IP address.
5.3.4. NAT
NAT Select this option to Activate/Deactivated the NAT (Network Address Translation)
function for this VC. The NAT function can be activated or deactivated per PVC basis.
5.3.5. Default Route
Default Route if enable this function, the current PVC will be the default gateway to
internet from this device.
5.3.6. Dynamic Route
RIP (Routing Information protocol) Select this option to specify the RIP version,
including RIP-1, RIP-2M and RIP-2B. RIP-2M and RIP-2B are both sent in RIP-2
format; the difference is that RIP-2M using Multicast and RIP-2 using Broadcast
format.
RIP Direction Select this option to specify the RIP direction. None is for disabling the
RIP function. Both means the ADSL Router will periodically send routing information
and accept routing information then incorporate into routing table. IN only means the
ADLS router will only accept but will not send RIP packet. OUT only means the ADLS
router will only send but will not accept RIP packet.
5.3.7. Multicast
IGMP (Internet Group Multicast Protocol) is a session-layer protocol used to establish
