Advanced Operation
Menu examples shown below are for the V3 control panel. Menus in some earlier panel versions may differ.
Access Level 1 (Normal): Controls Enabled LED off
At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the Controls Enabled
LED is switched off.
A valid access level code must be entered or the key switch must be used in order access any of the
menus.
Access Level 2A (User): Controls Enabled LED on
At Access Level 2A (User), the main Fire Alarm Controls are enabled, and the following System
Controls are accessible:
Delay Override
The Delay Override function overrides any programmed delays.
Test Display
The Test Display function causes the panel LEDs to illuminate, and the LCD screen to
blacken, and the panel buzzer to sound in order to verify their correct operation.
Press the Esc key to exit to the previous menu.
1. Delay Override
2. Test Display
To Next Page
