6 Specifications
6.1 Fire Detection
• Detection time and distance:
• 40ms
- for fast fire burst or explosion
• 1.5s
- for 1ft
2
(0.1m
2
) N-heptane pan fire at 100 ft (30m)
• 4s
- for 1ft
2
(0.1m
2
) N-heptane pan fire at 230 ft (70m)
• Field of view: 90° Horizontal, 75° Vertical
• Time Delay: 0-30 seconds (adjustable)
• Built-in test: Automatic and Manual
6.2 Video functionality
• HD Video allowing clear imaging of fire and people at 100ft. (30m) distance.
• Video recording of alarm events 1 minute before and up to 3 minutes after the flame is
detected.
• System integration protocol: ONVIF (Open Network Video Interface Forum) Profile S
6.3 Electrical Specifications
• Operating Voltage: 24 VDC nominal (18-32 VDC)
• Current Consumption:
• Standby 180mA
• Maximum 250mA all systems in operation (including window heater)
• Cable Entries: 2x conduit entries 3/4” 14NPT or M25x1.5
• Wiring: 12-20AWG (2.5-0.35mm
2
)
6.4 Outputs
• Relays: Volt-free contacts rated 2A at 30 VDC
• Alarm: Normally open
• Fault
2
: Normally open energized
• 0-20mA (stepped) current output: 3 wire and 4 wire configurations (sink and source).
The 0-20 mA output at different detectors status are define at the below table.
The max load of 0-20 is max 500 ohm at 18-32 VDC. The 0-20 mA is sink isolated and can be
configured as source.
2
The FAULT relay will normally be energized and the contact will be closed during normal operation of the
detector. The contact will be open at fault condition or low voltage.
