FIK-IR3-HD User Manual Doc. No. 06-932.02
For more information & Technical support: (800)-979-FIKE (3453) 19
Detector status
Output
Fault
0 mA or 1 mA ±10%
BIT fault
2 mA ±10%
Normal
4 mA ±10%
Alarm
20 mA ±5%
• Tri-colour LED indication
• Modbus RTU compatible protocol on RS-485
• Digital Video: IP network IEEE 802.3 10 Base-t
6.5 Mechanical Specifications
• Size: 7.87 x 5.12× 5.12″ (200×130×130mm)
• Weight:
• Detector (Stainless Steel 316): 9.8 lbs. (4.4 kg)
• Tilt mount (Stainless steel 316): 5.4 lbs. (2.4 kg)
6.6 Environmental Specifications
• Temperature Range:
• Operating -67°F to + 167°F (-55°C to +75°C)
• Option -67°F to + 185°F (-55°C to +85°C)
• Storage -67°F to + 185°F (-55°C to +85°C)
• Humidity: up to 99%, non-condensing
• Ingress Protection: IP66 & 68; NEMA 4X & 6P
