TWINFLEX
®
pro Repeater Panel Engineering and Commissioning Manual
15
Setting Repeater Number
Each repeater has to be set with a unique number address in the range 1 – 8, the default number is 1. If
more than one repeater is used on a single panel the repeater numbers will need to be changed, this is
done using DIL switches A0 to A2 located next to the buzzer.
Note: The DIL switches are only read on power up. The repeater must be powered down and back up
again for changes to take effect.
Address settings
Repeater Buzzer
The local repeater internal buzzer can be switched off using DIL switch SP1 (4) on the bank of switches
located next to the buzzer.
SP1 (4) set to On = buzzer on
SP1 (4) set to Off = buzzer off
This setting only affects the local buzzer and has no effect on the panel buzzer or other repeaters on
network.
Note: The DIL switches are only read on power up. The repeater must be powered down and back up
again for changes to take effect.
Powering Up
Having connected the power supply and peripheral bus to the repeater as described above. Power up
the repeater, the LEDs will flash and the Display will show a default screen:
Then after a short period of time the display will show the same date and time as displayed on the main
control panel it is connected to:
NOTE: If the default screen on the main control panel is changed the panel must be powered down and back up again with
the repeater connected in order to update the default screen on the repeater.
