Technical Data
Repeater Panel Specification
Dimensions (mm) 250 x 140 x 85
Weight 650 grams
Construction UL94-V0 rated ABS
Cable Entry 6 x 20mm knockouts, 4 x double 20mm knockouts
Cable type 2 core 1.5mm
2
screened fire rated cable
Operating voltage Nominal 24V DC (Range 21 - 32V DC)
Operating current Quiescent @ 24V DC 16 mA (back light off)
Operating current Max @ 24V DC 50 mA (controls enabled, back light on)
Communications Multi-drop RS-485
Total peripheral bus length 500m (max)
IP rating 20
Maximum number of repeaters per control
panel
8
Operating temperature 5
O
C to 50
O
C
