SYMBOLS USED ON THE MACHINE
Tap symbol
Used to indicate the solenoid valve switch
Brush symbol
Used to indicate the brush motor switch
Symbol denoting suction motor
Used to indicate the suction motor switch
Battery symbol
Battery charge level indicator
Indicates the maximum temperature of the detergent solution
Located near the solution tank inlet
Indicates the maximum gradient
