TECHNICAL DESCRIPTION
UM
Genie E
230 V
Genie E
110 V
Nominal input power [IEC 60335-2-72; IEC 62885-9] kW 0,54 0,54
Working width mm 360 360
Width of rear squeegee mm 440 440
Working capacity m
2
/h 1335 1335
Brushes (diameter or length)
 mm
356 356
Brush rpm rpm 140 140
Force exerted on the brushes N 174 174
Brush motor – Rated voltage V/Hz 230 - 50 110 - 50
Brush motor – rated power W 320 320
Forward speed type semi-aut. semi-aut.
Forward speed Km/h 3 3
Maximum gradient 2% 2%
Suction motor – Rated voltage V - Hz 230 - 50 110 - 50
Vacuum motor – Rated power W 220 220
Maximum vacuum [IEC 62885-9; IEC 60312-1] kPa 7,2 7,2
Solution tank l 7 7
Recovery tank l 9 9
Dimensions of the open machine (Length / Height / Width) mm 615x1105x465 615x1105x465
Dimensions of the closed machine (Length / Height / Width) mm 885x425x465 885x425x465
Machine weight when empty kg 30 30
Transported machine weight kg 30 30
Weight of the machine when ready for use (GVW) kg 40 40
Sound pressure level in operator seat [ISO 11201] (LpA) dB 66.1 66.1
Uncertainty K
pA
dB 1.4 1.4
Hand-arm vibrations [IEC 60335-2-72; IEC 62885-9; ISO 5349-1] m/s
2
2 2
Uncertainty 3,5% 3,5%
