FingerTec R2 User Manual

9
1
2 3
4
5 6
7
8
0
9
ESC
OK
MENU
Back Plate
4 feet / 1.2 meter
(recommended)
CONTENTS
3 • CONNECTION – SYNCING TERMINALS
Installations
FingerTec terminals offer several connections for power and communications. Installa-
tions of FingerTec time attendance terminals are simple.
mounT on wAll
Attached the back plate on the wall securely and attach the terminal to the back plate
when mounting it on the wall.
Communications
Connection points for power and communication are available on top of the termi-
nals. Refer to the following diagrams for the terminals you require.

FingerTec R2 Specifications

General

Brand	FingerTec
Model	R2
Category	IP Access Controllers
Language	English
