8.3.2 Models 130-170-200-250-300-600 2t-400-500 (1T/2T)
Remove the frontal bottom cover using a screwdriver for all the equipment with the
refrigeration unit in the bottom part (n.3 screws).
Using a vacuum cleaner, an air jet or a dry brush clean the heat exhanger fins of the
condenser.
Fix the back cover again. Connect the equipment to the mains and switch it on.
8.3.3 Models 700-1500
In models with refrigeration unit in the upper part (700-1500 lt), the condenser is directly
accessible using a step ladder to reach the top of the appliance.
Using a vacuum cleaner, an air jet or a dry brush clean the heat exhanger fins of the
condenser.
Connect the equipment to the mains and switch it on.
