Program Features and Options
LDMs, LED-10 series and ACM-8RFs, be certain that none of the other devices are set to address 01. For proper
supervision of all annunciators, only one AFM series annunciator (fixed at address '01') should be installed.
Trouble Reminder
The Trouble Reminder feature provides an audible reminder that an alarm or trouble still exists on the FACP after
the control panel has been silenced. The factory default for this feature is 'disabled'. When this feature is 'enabled',
the control panel piezo sounder will pulse once every 15 seconds during an alarm and every two minutes during a
trouble condition, after the Signal Silence or Acknowledge switch is pressed. The piezo will continue to sound at
these rates until the alarm or trouble condition is cleared.
Silence Inhibit
The Silence Inhibit feature prevents the silencing of Notification Appliance Circuits, using the Signal Silence
switch or Reset switch, for the amount of time corresponding to the selected option, after the NACs are activated.
The factory default for this feature is 'disabled'
TABLE 3-10:Annunciator Addressing - Zone 8 Alarm LED
Zone Trouble LED Number (yellow) Highest Installed Annunciator Address
1 01 - default
202
303
404
505
606
707
808
909
10 10
TABLE 3-11:Trouble Reminder - Zone 9 Alarm LED
Zone Trouble LED Number (yellow) Trouble Reminder
1
Disabled = LED Off (factory default)
Enabled = LED On
TABLE 3-12:Silence Inhibit - Zone 10 Alarm LED
Zone Trouble LED Number (yellow) Silence Inhibit
1 Disabled (factory default)
2 30 Second Silence Inhibit
3 60 Second Silence Inhibit
4 90 Second Silence Inhibit
5 120 Second Silence Inhibit
