Product Features
8
Document #50801 Rev.B 8/17/98 P/N 50801:B
Optional
Transformer
Standard
Transformer
24 VDC
Power
Relays
Notification
Appliance
Circuits
10 Input
Zones
LED-10IM
Interface
Module
Connector
Holds up to 7 AH Batteries,
FIGURE 1-2:
MS-2410BC Panel
Remote
Trouble
Buzzer
Keypad and
LEDs
Reverse
Polarity
Module
Reverse
Polarity
Module
Supervision
Security Key
