Vertical balanced flue kit - max flue length 6 m
Low level balanced flue kit - max length 3 m
Hign level balanced flue kit - max length 6 m
Overall length must take into account bends
where 45° bend = 0.5 m length and
90° bend = 1 m length
INSTALLATION INSTRUCTIONS SUPPLIED WITH ALL FLUE KITS
Elbows: 45°, 90°
Adjustable extensions:
305-420mm, 555-920mm
Extensions: 250mm, 500mm, 1000mm
FIREBIRD ENVIROMAX BALANCED FLUE SYSTEMS
6
21
6.6 INSTALLATION - VENTILATION & COMBUSTION AIR REQUIREMENTS
