10.3 - PARTS & BAFFLES - SLIMLINE SYSTEMPAC BOILER
No. Description Slimline Heatpac C20, C26, C35 Slimline Systempac C20, C26, C35
1 Boiler Shell 312134 312733
2 Heat Deflector 210904 210904
3 Tube Baffle 1 Way 110908 (5 off ) 110908 (5 off )
4 Tube Baffle 4 Way 110907 (4 off ) 110907 (4 off )
5 20/26/35 kW smoke baffle 212022 / 212028 / 212122 (4 off) 212022 / 212028 / 212122 (4 off)
6 Door Gasket 111314 111314
7 Door Duroboard 110918 110918
8 Door 210910 210910
9 Burner Flange Gasket ZE3005787 ZE3005787
10 Burner Flange n/a n/a
11 Burner 410205 / 401206 / 410207 410205 / 401206 / 410207
12 Condensate Trap 112184 112184
13 Condensate Hose 500mm 111537 111537
14 Flue Ring Gasket 112104 112104
15 Vessel Bracket n/a 210962
16 12L Pressure Vessel n/a 110658
17 Flangeless Plug 110923 110923
18 Stat Pocket 111317 111317
19 Left Top Bracket 211603 212894
20 Right Top Bracket 211603 211603
21 Casing Base 211594 211594
22 Boiler to Base Bracket 211600 211600
23 Casing Front 211604 211604
24 Casing Front Lagging 112010C 112010C
25 Boiler Lagging 110917 110917
26 Casing Side Lagging 112010D 112010D
27 Casing Top Lagging 112010E 112010E
28 Casing Flue Outlet Lagging 112010B 112010B
29 Casing Back Lagging 112010A 112010A
30 Casing Left Side 211607 211607
31 Casing Right Side 211608 211608
32 Casing Top 211609 211609
33 Casing Back 211605 211605
34 Casing Flue Outlet 211606 211606
35 Control Panel 311146 313261
- Pressure Switch n/a 110607
36 Terminal Guard Plate 213027 213027
37 Terminal Guard 111289 111289
38 Flue Seal 110721 110721
39 Flue Kit 411482 411482
40 Flue Bend 90˚ 413006 413006
41 Cone 412049 412049
42 Flexible Hose n/a n/a
43 System Pipe No. 3 n/a 110971
44 G1/2" to 15mm BSP Compression n/a 111331
45 Double Check Valve n/a 111332
46 Flexible Hose G 1/2" 400mm n/a 111341
47 System Pipe No. 1 n/a 110969
48 System Pipe No. 2 n/a 110970
49 Pressure Switch n/a 110607
50 Auto Air Vent n/a 111327
51 Pump Valve n/a 110644
52 Circulating Pump n/a 410647
53 Recessed Pump Adaptor n/a 110648
54 Compression Union n/a 112000
55 Safety Release Valve n/a 111353
