10.1 - PARTS & BAFFLES - SYSTEM BOILER
No. Description C20 C26 C35 C44
1 Boiler Shell 312133 312133 312133 311783
2 Heat Deflector 210904 210904 210904 211643
3 Tube Baffle 1 Way 110908 (5 off) 110908 (5 off ) 110908 (5 off ) 111502 (8 off )
4 Tube Baffle 4 Way 110907 (4 off) 110907 (4 off ) 110907 (4 off ) 111503 (6 off )
5 Smoke Baffle 212022 (4 off ) 212028 (4 off ) 212122 (4 off ) 211651 (8 off )
6 Graphite Door Seal 111314 111314 111314 111646
7 Door Gasket 110918 110918 110918 111645
8 Boiler Door 210910 210910 210910 211644
9 Burner Insulation Gasket ZE2567398 ZE2567398 ZE2567398 ZE2567398
10 Burner Flange ZE2567398 ZE2567398 ZE2567398 ZE2567398
11 Burner 410205 410206 410207 410209
12 Condensate Trap 112184 112184 112184 112184
13 Condensate Hose 111537 111537 111537 111537
14 Drain Cock 111329 111329 111329 111329
15 Pressure Vessel Bracket 210962 210962 210962 n/a
16 Pressure Vessel 110658 110658 110658 110755
17 Jubilee Clip 110481 110481 110481 110841
18 Air Hose 111902 111902 111902 111902
19 Casing Left Bracket 212321 212321 212321 211805A
20 Casing Back Bracket 210916 201916 210916 211770
21 Casing Right Bracket 210915B 210915B 210915B 211797
22 Casing Front Insulation 110937 110937 110937 111788
23 Casing Front 111376 111376 111376 111787
24 Casing Left Panel 111374A 111374A 111374A 111786
25 Casing Right Panel 111374B 111374B 111374B 111792
26 Casing Side Blank 1 113031 113031 113031 n/a
27 Casing Side Blank 2 113032 113032 113032 n/a
28 Casing Top 111375 111375 111375 111793
29 Casing Flue Blank 111388 111388 111388 111586
30 Casing Flue Trim 111397 111397 111397 111587
31 Casing Top Insulation 111794 111794 111794 111789&111791
32 Casing Back Support 111596 111596 111596 111790
33 Control Panel 311670 311670 311670 313320
34 Casing Base 210914 210914 210914 211795
35 Flue Gasket 112104 112104 112104 112105
36 Flue Gas Analysis Blank 110923 110923 110923 110923
37 Filling Loop Hose 111341 111341 111341 111341
38 Double Check Valve 111332 111332 111332 111332
39 Compression Unit 15mm 111331 111331 111331 111331
40 System Pipe 3 110971 110971 110971 n/a
41 Pressure Vessel Hose 110660 110660 110660 110660
42 Stat Pocket 111317 111317 111317 111317
43 Pipe Work See detail drawing See detail drawing See detail drawing See detail drawing
44 Lagging Jacket 110917 110917 110917 111653
45 System Pipe 1 110969 110969 110969 111348
46 System Pipe 2 110970 110970 110970 n/a
47 Compression Unit 22mm 112000 112000 112000 n/a
48 Pump Valve 110644 110644 110644 110644
49 Recessed Pump Adapter 110648 110648 110648 110760
50 Safety Release Valve 111353 111353 111353 111353
51 Circulating Pump 410647 410647 410647 414040
52 Automatic Air Vent 111327 111327 111327 111327
53 Pressure Switch 110607 110607 110607 110607
54 Manual Air Vent n/a n/a n/a 110645
55 Check Valve n/a n/a n/a 111820
56 Elbow n/a n/a n/a 110756
57 Gate Valve n/a n/a n/a 110758
58 Reducing Bushing n/a n/a n/a 110735
59 Reducing Bushing n/a n/a n/a 110764
60 Reducing Nipple n/a n/a n/a 110763
61 Nipple n/a n/a n/a 110675
62 Pressure Switch Adapter n/a n/a n/a n/a
