10.2 PARTS & BAFFLES - KITCHEN (BASIC) & COMMERCIAL UTILITY BOILERS
No. Description
C12-18 C20/26 C35 C44 C58 C73 C100
1 Boiler Shell 312808 312026 312026 311634 311634 311481 312422
2 Heat Deflector 212810 210904 210904 211643 211643 211500 212420
3 Tube Baffle 1 Way 110908 (7 off ) 110908 (5 off ) 110908 (5 off) 111502 (8 off ) 111502 (8 off ) 111502 (11 off ) 111502 (10 off )
4 Tube Baffle 4 Way 110907 (2 off ) 110907 (4 off ) 110907 (4 off) 111503 (6 off ) 111503 (6 off ) 111503 (6 off ) 111503 (12 off)
5 Smoke Baffle 212809 212028 (4 off ) 212122 (4 off ) 211651 (8 off ) 211640 (8 off ) 211501 (8 off) 212419 (8 off )
6 Graphite Door Seal 111314 111314 111314 111646 111646 111511 112414
7 Door Gasket 112813 110918 110918 111645 111645 111506 112362
8 Boiler Door 212811 210910 210910 211644 211644 111505 212423
9 Burner Insulation Gasket 3005787 3005787 3005787 3005787 3005795 3005795 3005795
10 Burner Flange 3006384 3006384 3006384 3006384 3008637 3008637 3008637
11 Burner 413886 410206 410207 410209 410210 410210 410210
12 Condensate Trap 112184 112184 112184 112184 112184 112184 112184
13 Condensate Hose 111537 111537 111537 111537 111537 111537 111537
14 Drain Cock 111329 111329 111329 111329 111329 111329 111329
15 Back Bracket 210916 210916 210916 211770 211770 211591 213105
16 Stat Pocket 111317 111317 111317 111317 111317 111317 111317
17 Lagging Jacket 113029 110917 110917 111653 111653 111438 112633
18 Casing Left Panel 111377A 111377A 111377A 111761 111761 111580 213108
19 Casing Right Panel 111377B 111377B 111377B 111766 111766 111853 213111
20 Casing Top Panel 114102 111375 111375 111764 111764 111582 213120
21 Casing Front Panel 114103 111376 111376 111762 111762 111581 213122
22 Casing Door Insulation n/a n/a n/a n/a n/a n/a 112634
23 Casing Door Panel n/a n/a n/a n/a n/a n/a 212616
24 Air Hose 111902 111902 111902 111902 111902 110501 110501
25 Flue Gasket 112104 112104 112104 112105 112105 112713 112712
26 Control Panel 314111 311670 311670 311706 311706 311707 313117
27 Side Flue Blank 113031 113031 113031 n/a n/a n/a n/a
28 Side Half Moon Blank 113032 113032 113032 n/a n/a n/a n/a
29 Top Flue Blank 111388 111388 111388 111586 111586 111803 213121
30 Top Half Moon Blank 111397 111397 111397 111587 111587 111802 n/a
31 Top Panel Insulation 114105 111794 111794
111765 & 112011 111765 & 112011
111592 A&B
113124 & 113125
32 Casing Back Support 214104 111596 111596 111767 111767 111585 213116
33 Right Bracket 210915B 210915B 210915B 211805B 211805B 211806B 211590A
34 Left Bracket 210915A 210915A 210915A 211805A 211805A 211806A 211590B
35 Casing Front Insulation 114106 110937 110937 111763 111763 111593 113123
36 Casing Base 214101 210914 210914 211769 211769 211589 213106
37 Casing Top Stiffener n/a n/a n/a n/a n/a n/a 213104
38 Casing Back Panel n/a n/a n/a n/a n/a n/a 213119
