Components of a Model 235, 350, 500 Heater:
Heat Exchanger with Cabinet (remove fan, accessories, & target from inside the chamber)
Burner (factory test fired burner in shaped foam packaging, save box should shipping be needed)
Accessory Carton (Cleanable Oil Filter, Fan Motor, 1/2" Cutoff valve, 3/4" Suction Screen, 3/4"
Check Valve, Wall Thermostat, 1/2” x 1/4” Swivel, 3/4” x 1/2” Swivel, 1/4” x 1/4” x 1/8” Tee, 1/4”
x 1½” Hex Nipple, 1/2" x 2 Hex Nipple, 1/4" x 2" Nipple, Warranty Card & Manual , (2) Pressure
Gauge)
Barometric Damper (for chimney)
Oil Transfer Pump
Fan
Heat Exchanger w/ Cabinet
Remove this cabinet panel to slide out fan, accessories carton, damper, and access target.
BURNER
(appearance varies by model)
