Page 7 of 7
MODEL 155, 200, 245, 315
HEATER COMPONENTS IDENTIFICATION
STACK OUTLET BLOWER LOUVER PANEL
(STACK CAP OPPOSITE SIDE) (BLANK PANEL OPPOSITE SIDE)
BAROMETRIC DAMPER
STACK BURNER DOOR
SIDE PANEL BASE DOOR GASKET VIEW PORT BURNER
(2) Bolt on brackets each end for attaching to framework or rods. Can be put on lower edge too.
BLOWER/GUARD FAN SWITCH 6 X 6 ELECTRICAL BOX
CORD LOCKING CLAMP BEHIND BRACKET PREVENTS BURNER DOOR FROM
OPENING WHILE POWERED. TAKE SLACK FROM CORD WHEN INSTALLING.
