ASSEMBLY
Install the Handle
The generator requires some assembly prior to
1. Place the handle K over the mounting channel usage. If problems arise
when assembling the
on the frame. generator,
call 1-844-347-6261.
2. Secure the handle to the frame using the two
Install the Wheel Kit handle flange bolts H(M8x50).
3. Place a flange nut F (M8) on the end of
each bolt and fasten securely with provided
The wheel kit is not intended for over-the-road wrenches.
use.
DO NOT over tighten the flange nuts.
1. Before adding wheels, tip the generator on
its
side.
2. Slide the axle pin A through the wheel B.
3. Slide the axle pin A through the mount point on the frame and flat washer D.
4. Secure the wheel and axle pin with the cotter pin C.
5. Repeat steps 2-4 to attach another wheel.
Install the Support Leg
1. Attach the support leg G to the
generator frame with flange bolts E (M8x16) and
flange lock nuts F(M8).
2. Tip the generator slowly so that it rests
on the wheels and support leg.
3.Tighten bolt E and nut F with provide wrenches.
