P08004 PARTS LIST
NO.
Part Number
Description
Qty.
NO.
Part Number
Description
Qty.
1
380713522
FIRMAN 439cc Engine
1
67
357713533
Isolator A
2
2
357713501
Rubber Cap B
1
68
357713534
Wheel
2
3
336713528
Flange. Bolt M6×8
3
69
357713535
Axle Assy
2
4
357713502
Generator Wind Shield
1
70
357713536
Lock Pin
2
5
380713501
Rotor Assy
1
71
357713550
Butterfly Nut M6
2
6
380713502
Stator Assy
1
72
357713551
Battery Pressing Bracket
1
7
380713503
Stator Cover
1
73
357713552
Rubber Pad
1
8
357713506
Generator End Cover
1
74
357713553
Battery
1
9
357713507
Carbon Brush Assembly
1
77
357713555
Bolt, Bend Hook
2
10
336713525
Carbon Brush Holder
1
78
336713611
Cable Boot
1
11
357713563
Bolt &washer Assemblies
1
79
357713556
Battery Red Wire +
1
12
357713564
AVR
1
80
357713557
Battery Black Wire -
1
13
336713519
Flange. Bolt M5×16
2
81
336713578
Nut M5
2
14
336713523
Terminal Block
1
82
336713558
Nut M8
4
15
336713520
Bolt M5×16
2
83
336713514
Ground Wire
1
16
336713522
Ground Wire
1
84
336713516
Star Washer Ø6
1
17
357713509
Generator End Cover Cap
1
85
336713517
Nut M6
3
18
336713507
Flange. Bolt M5×12
3
86
336713559
Flange. Bolt M8×16
2
19
380713506
Flange Bolt M6×200
4
87
357713538
Support Leg
1
20
336713512
Lock Washer Ø6
4
88
336713557
Rubber, Support
2
21
336713513
Flat Washer Ø6
4
89
336713561
Flange. Bolt M6×25
2
22
380713507
Side Cover Bolt M5×229
2
90
336713564
Grommet
1
23
357713511
Lock Washer Ø5
2
91
336713565
Screw M5×14
3
24
336713577
Nut M5
4
92
357713539
Control Box
1
25
380713508
Flange Bolt M10×285
1
93
336713569
Screw&washer Assy M4×8
10
26
357713513
Lock Washer Ø10
1
94
336713568
Nut M4
15
27
357713514
Washer Ø10
3
95
380713524
Circuit Breaker 33A
2
28
336713531
Flange. Bolt M8×20
4
96
357713565
Charging Module
1
29
357713515
Bracket Muffler
1
97
336713620
Diode Module
1
30
336713515
Flange. Bolt M6×12
12
98
357713566
Remote Module
1
31
357713516
Guard, Muff.,Side
1
99
336713567
Nut M3
2
32
336713538
Screw&washer Assy M5×14
2
100
336713570
Multi Meter
1
33
357713517
Holder, Spark Arrester
1
101
336713619
Switch
1
34
336713536
Arrester, Spark
1
102
380713525
Control Panel
1
35
357713518
Guard, Muff.,Front
1
103
336713616
Engine Switch
1
36
336713534
Nut M8
2
104
336713617
Battery Switch
1
37
336713509
Lock Washer Ø8
2
105
336713618
Pilot Lamp
1
38
336713533
Flat Washer Ø8
2
106
336713574
Outlet Cover TT-30R
2
39
357713519
Cover, Handle
1
107
336713573
Outlet Cover L5-30R
2
40
357713520
Gskt.,ext.
1
108
380713512
Bolt M6×22
1
41
380713509
Muff.,assy.
1
109
380713513
Washer Ø6
2
42
357713522
Handle
1
110
380713514
Lock Washer Ø6
2
43
357713523
Guard, Muff.,Back
1
111
380713515
Nut M6
2
44
357713524
Rubber Cap A
1
112
336713575
Outlet Cover 5-20R
1
45
336713590
Pin, Shaft
1
113
357713545
Grommet
1
