– 30 –
Accessing Other Panels (cont’d)
Press 0 to exit mode. After a few seconds, the keypad displays the status
of the original partition of the original panel for the keypad. Also, this mode
will end in approximately 2 minutes if no keys are pressed.
NOTES:
When performing any of the arming commands, if there are faults in any of
the partitions of a panel, the system will not arm that panel, but will arm all
the other partitions of the other panels.
When performing either a STAY or INSTANT arm command the system
always arm in mode 1.
The user cannot execute another panel linking mode. To execute another
panel linking mode or to access a different remote panel, the user must first
exit this mode (return to the original control panel).
Priority of Displays for Multi-Partition and Multi-Panel Modes
This table shows the priority of displays if more than one of the conditions
exists at the same time.
Priority Description Display
1 Fire Alarm F
2 All Other Alarms
✴
3 AC Loss P
4 Comm Fail C
5 System Low Battery L
6 Trouble T
7 Bypass B
8 Not Ready N
9 Ready R
10 Armed STAY S
11 Armed AWAY A
12 Armed INSTANT I
13 Armed MAXIMUM M
