Item Part Number Description QTY Item Part Number Description QTY
1 70102 Left Main Frame 1 42 10084 Bungee Pulley 10
2 73104
Lower Tank Bracket
2 43 73411 Pulley Shaft Bolt 10
3 73105
Upper Tank Bracket-Left
1 44 10086
C Clip RTW-35
10
4 70111
Upper PVC Cover Bracket
1 45 73008 M12*70 bolt 2
5 70113
Bungee Hook
1 46 73003 M12*50 bolt 2
6 70114 Support Bracket 1 47 71009 Inspection Plate 1
7 70103 Upper to Lower Frame Mounting Bracket 1 48 10070
Screw M4x10
2
8 20029 Nylock Nut M10 3 49 10190
Washer M8
1
9 70116 Rower Belt Guides 2 50 70311 Flywheel Plate 1
10 70105
Upper Tank Bracket-Right
1 51 70312 Flywheel Shaft 1
11 73103 Upper to Lower frame Welded Assembly 1 52 10047
Impeller Blade
9
12 70112 Rope Pulley Bracket 4 53 10033
Stainless Washer 10x4.2x1
22
13 73106 Tank Tensioning Bracket 1 54 10034
Stainless Nut M4
22
14 71036 M8 nut (Note: For tank tensioning bolt) 5 55 10035
Stainless Bolt M4
22
15 73104 M12 Nut 4 56 70313 Impeller Shaft 1
16 70110 Lower Perspex Mounting Bracket 3 57 10022 Aluminum Tank Back 1
17 73101
Right Main Frame
1 58 10185
Bearing Housing
1
18 73201 Transport Wheel Frame 2 59 10012 NSK 6005ZZ Bearing 2
19 73210 PU Transport wheel 2 60 10025
Seal NBR 37x30x8t for Flywheel Shaft
1
20 60808 M8 Screw 4 61 10145
Bearing Spacer
1
21 60708 Washer M8 8 62 10186
RTW-48 C-Clip
1
22 73006 M8x60 bolt 2 63 73003 M12x50 Bolt 1
23 60709
Nut Nylock (M8)
2 64 10163 Stainless Shaft 1
24 73050
End Cap 20x40
2 65 10164 Adjuster Handle Shaft Base 1
25 71018 Tank Bolt Adjuster Washer 1 66 10028
Stainless 0.8mm Backing Plate
1
26 10063
Bolt M12x30
4 67 13045
PC Tank Cover
1
27 10043
Washer M12
8 68 10030
Blue Adjuster PP Tank Ring 358x10
1
28 10042
Nut M12 Nylon
4 69 10036
Screw M3x20 SS for Blue Tank Ring
12
29 70501 Computer Stalk 2 70 70320
Blue tank ring holding screw stainless steel
M3x20
1
30 70502 Computer mounting Bracket 2 71 10162
Grub Screw M8x10
2
31 10114
Bushing 20x16x13x10
3 72 10184
Adjuster Handle (Includes PU yellow cover
#10193)
1
32 60606
Plastic Spacer M4
2 73 10193 PU Yellow Adjuster Handle Cover 1
33 10170
Washer M4
3 74 10032
Nylon Resistance Adjuster O ring 12x9x1.5
2
34 71017 M4x15 Bolt 2 75 10039
Tank Plug O Ring 32x3.5
2
35 73801 102mm Rope Pulley 1 76 10046
Tank Large Seal
1
36 60112 Belt pulley bearing 6000ZZ 2 77 10062
Bolt M3x12
12
37 10082
Washer M10
6 78 10044
Tank Black Outer Cover Ring
1
38 10096 Bolt M10x70 for Aluminum Rail 2 79 70321/10207
Tank Plug 2
39 10097
Nut M10
2 80 70323 Sticker 1
40 60105 Computer Bolt Spacer 1 81 71029 Computer 1
41 71011 Bungee Pulley Spacer 10
