CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Connector 5 (CN5), 4-Pin (RS 232 Data Port)
This connector is used for updating control modules via www.firstechonline.com. You must also use this
port to flash Blade bypass modules. This port provides simple connectivity of Fortin and iDataLink bypass
modules.
This port is also used to communicate with DroneMobile controllers. Make sure to use the data port from
the DroneMobile unit to this RS232 port.
Connector 6 (CN6), 4-Pin DAS Sensor Input
This connector is designed for used with the Firstech DAS sensor. This is an optional input for use with the
upcoming DAS sensor. It will detect movement of the vehicle in failsafe with the reservation mode.
Connector 7 (CN7), 4-Pin to 4-Pin or 6-Pin (Pre-wired Antenna Cable)
Connect your antenna cable to this port. You can only use 4 to 4 pin or 4 to 6 pin antenna cables. 6 to 6
Pin antenna cables do not work. Do not use both Connector 9 and Connector 10 at the same time.
Pin 1 Yellow - RX input. This wire receives the signal from remote.
Pin 2 White - TX output. This wire transmits the signal to remote.
Pin 3 Red – Constant 12V positive (+) output.
Pin 4 Black – Negative (-) ground.
Connector 8 (CN8), 6-Pin to 6-Pin (Pre-wired Antenna Cable)
Connect your antenna cable to this port. You can only use 6 to 6 pin antenna cables. 4 to 4 or 4 to 6 Pin
antenna cables do not work. Do not use both Connector 9 and Connector 10 at the same time.
Pin 1 Red - Constant 12V positive (+) output.
Pin 2 White - TX output. This wire transmits the signal to remote.
Pin 3 Orange - Constant 5V output
Pin 4 Yellow - RX input. This wire receives the signal from remote.
Pin 5 Black – Negative (-) ground.
Pin 6 Blue - RX/TX control
Connector 9 (CN9), 2-Pin (Pre-wired Thermister)
Plug optional thermister into this connector to monitor the vehicle’s temperature. It used in conjunction with
Timer Start features along with displaying temperature on two-way LCD’s. To use Timer Start features review
Option Group 2. IMPORTANT: Thermister plugs are blue 2 pin connectors on the CM6 series but old
white plug Thermisters will still work.
Copyright 2012 Firstech, LLC.
Page 18
