Firstech CM6200 User Manual

Connector 10 (CN10), 2-Pin (Pre-wired LED)
Note: Do not mistake for Thermister port.
Pin 1 Black - L.E.D negative (-) ground.
Pin 2 Black/White- L.E.D. 3V positive (+) output.
Connector 11 (CN11), 3-Pin (Pre-wired Valet/Programming Switch)
Pin 1 Gray/Black - Negative (-) ground.
Pin 2 Gray – 3V positive (+) L.E.D. output.
Pin 3 Gray – Negative (-) output.
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Option Programming Tables CM6200
Copyright 2012 Firstech, LLC.
Page 19
Option Group 1
Feature Default Setting - I Optional Setting - II Optional Setting - III Optional Setting - IV
1-01
Unlock before, Lock after, starting Off On
Lock After Remote Start
Only
Lock After Shutdown
Only
1-02
Lock / Unlock pulse duration 0.8 sec 2.5 sec 0.125 sec 3.5 sec
1-03
Driver's priority unlock Off On
1-04
Double pulse unlock Off Unlock Lock Both Lock and Unlock
1-05
Rearm Output
After Start Shutdown and
First Lock
After Start Shutdown and
Every Lock
After Start Only After Shutdown Only
1-06
Reservation Lock
(Manual transmissions)
Locks Before Reservation
Mode is Set
Hold Start Button for
2.5 sec. to Activate
Reservation Mode
Reservation Sets 10
Seconds After the Last
Door is Closed
Locks After Reservation
Mode is Set
1-07
Unlock / Disarm With Trunk
Release
Unlock, Factory Disarm,
and Trunk Release
Factory Disarm, Trunk
Release Only
Trunk Release Only
1-08
Passive Mode Off
Passive locking with
Passive Arming
No Passive Locking with
Passive Arming
1-09
Ignition controlled door locks Off On
RPM Locks (Tach Sensing
Mode Only)
1-10
Auto Relock
(If a door is not opened within
this amount of time)
Off 30 sec 60 sec 5 min
1-11
Ignition / Accessory Out Upon
Unlock
Off
Ignition Pulse - same
timing as disarm pulse
Acc Pulse - same timing
as disarm pulse
Ignition and Acc Pulse -
same timing as disarm
pulse
1-13
Double Pulse Disarm Input Single Pulse Double Pulse
1-14
Auto Mode Off
FT-EZGO Unlock for
FTX
FT-EZGO Unlock
FT-EZGO Lock and
Unlock
1-15
Trunk Output Timing 1 sec 2 sec 3 sec 4 sec
