Option Menu Descriptions CM6200
1-01 Unlock Before, Lock After Starting - If enabled, this feature will make the system unlock the doors
before remote starting, start the vehicle, then lock the doors after the vehicle starts. It will then lock
the doors again if the remote start run time expires and the vehicle shuts down. This feature is for
vehicles that have factory alarms that need to be disarmed before remote starting.
1-02 Door Lock/Unlock Pulse Duration - This feature determines the output duration of the door lock
and unlock pulses. Some vehicles do not respond to short door lock/unlock pulses. This does not
affect the output of the factory arm (orange wire CN3)or factory alarm disarm (orange/white wire
CN3).
1-03 If enabled, this feature will allow the user to unlock the driver’s door first, and if the unlock button
is pressed again within 4 seconds, the other doors will unlock. The driver’s door unlock must be
isolated from the other doors and use the blue (-) unlock. The Orange/Black CN4 will be used for
your 2nd Unlock output to unlock all other doors.
1-04 Double Pulse Unlock - If enabled, this feature will generate a double pulse output for lock, unlock,
or both lock and unlock outputs. This can be used for vehicles that need two pulses to unlock or
relock the doors.
1-05 Rearm Output - These feature options change the event trigger on the Factory Alarm Rearm.
(Orange wire POC 6 CN3)
Copyright 2012 Firstech, LLC.
Page 22
Special Option Group 2
Feature Setting and OP500 Value
Programmable
Output Connector
0 - Default Setting 1~22 – Optional Settings
1 POC #1 (-) 2nd Parking Light (Green/White)
2nd Light - [1] 2nd Start - [2] 2nd IG1 - [3]
2nd Acc - [4] Status Out - [5] Rearm Out - [6]
Disarm Out - [7] Horn Out - [8] Dome Light - [9]
Aux 1 Out - [10] Aux 2 Out - [11] Aux 3 - [12]
Aux 4 Out - [13] Aux 5 Out - [14] Aux 6 Out - [15]
Aux 7 Out – [16] Defrost - [17] GWA - [18]
Status 2 For Manual Trans. - [19] Siren 2 - [20]
Defrost 2 - [21] VAC - [22]
2 POC #2 (-) 2nd Start (Red/Black)
3 POC #3 (-) 2nd Ignition (Green)
4 POC #4 (-) 2nd Accessory (White/Black)
5 POC #5 (-) Status/GWR (Black)
6 POC #6 (-) Rearm Wire (Orange)
7 POC #7 (-) Disarm Wire (Orange/White)
8 POC #8 (-) Horn (White)
9 POC #9 (-) Auxiliary 1 (Violet)
To Next Page
