CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Option Programming CM6200
Option Programming Using the OP500 (programmer)
The OP500 can be used to program any available option. It is required to program options in Special Op-
tion Groups 1 and 2.
STEP 1: Make sure system is unlocked/disarmed. Using the blue connector on the top of the
OP500, connect it to the control module via the antenna wire. (Use the included extension cable if neces-
sary.) Once connected, the OP500 will power up as long as the main ignition harness to the controller has
been connected properly.
STEP 2: To change the option number you wish to program, use the left and right arrow keys on the
OP500. It will scroll through the options available in menu 1 and then move to menu 2, then 3 and 4. Use
the up and down arrow buttons on the OP500 to adjust the option settings; “1” is the default setting, and
“2”, “3”, and “4” are the optional settings.
Copyright 2012 Firstech, LLC.
Page 29
Special Option Groups 1 & 2 CM6200
IMPORTANT: The OP500 is required to change settings in Special Option Groups 1 and 2.
Special Option Group 1
1 Diesel Timer – Option 2-03 must first be set to setting 2. This special option allows a specific wait to
start time (in seconds) to be programmed. This prevents the need for a timer relay and eliminates a
connection to the “wait to start” wire.
2 Aux 1 Output Timing – Option 4-01 must first be set to setting 4. This special option allows a
specific output duration for Aux 1 to be programmed.
3 Aux 2 Output Timing – Option 4-02 must first be set to setting 4. This special option allows a
specific output duration for Aux 2 to be programmed.
4-8 Aux 3 – 7 Output Timing – Option 3-11 must first be set to setting 2 and the optional Auxiliary
settings module must be used. These special options allow specific output durations to be set for Aux
3 – 7. Only available with 2 Way LCD remotes.
Special Option Group 2
This special option group allows you to determine the output type of the POC wires. For example, if you
want to set POC #5 (default setting status out) to Aux 1, you will need change special option 5 to number
10. This must be done with the OP500.
