Maintenance Instructions
18.12.15 Kapitel/Chapter 7: Maintenance Instructions - Seite/Page 141
Fig. 7.12.2-28: Mount the ball bearingBy doing that, the ball bearing is pressed onto the shaft.
If necessary, hold the crank shaft with an appropriate
wrench to keep the diesel engine from rotating
concurrently.
Press the ball bearing on as far as possible.
(Tool: Wrench SW13 and SW22)
Fig. 7.12.2-29: Hold up the crank shaft
Fig. 7.12.2-30: Remove toolsRemove tools
