Maintenance Instructions
Seite/Page 148 - Kaptitel/Chapter 7: Maintenance Instructions 18.12.15
7.14.2 Alternative replacement of the air filter mat with pull out holder
Fig. 7.14.2-1: Air suction housing with pull out holder 1. Air filter housing with pull out holder.
Fig. 7.14.2-2: Air suction housing with pull out holder 2. Tip the two fasteners 90°.
Fig. 7.14.2-3: Air suction housing with pull out holder 3. Pull the filter mat holder out.
