Maintenance Instructions
Seite/Page 116 - Kaptitel/Chapter 7: Maintenance Instructions 9.2.16
Fig. 7.19-3: Thermoswitch3. Disconnect electric supply line of the thermoswitch.
Fig. 7.19-4: Thermoswitch4. Loosen thermoswitch with a wrench with W.A.F. 22 mm.
Fig. 7.19-5: Thermoswitch5. Before installing the new thermoswitch, check the label for
correct item.
6. To reinstall, reverse the order of steps.
