9. Tables
9.1 Technical data
Fig. 9.1-1: Technical data
² progressive speed by VCS
³ 0,35 l/kW electrical power, the randomized values between 30 % and 80 %
of the rated speed
Fig. 9.1-2: Technical data
Panda 4000s
Panda 4,5ND
Panda 4200 FCB 4500FCB Panda 4k
Panda 5k
Panda 5000 LPE
Type Farymann
18W430
Farymann
18W430
Farymann
18W430
Z482 EA300
Governor mechanic mechanic mechanic mechanic
VCS
VCS
Automatic start booster yes yes yes no no
Cylinder 11121
Bore 82 mm 82 mm 82 mm 67 mm 75 mm
Stroke 55 mm 55 mm 55 mm 68 mm 70 mm
Stroke volume 290 cm³ 290 cm³ 290 cm³ 479 cm³ 309 cm³
Max. power (DIN 6271-NB) at 3000 rpm 5,7kW 5,7kW 5,7kW 9,32kW 5,1kW
Rated speed 3600 rpm 3600 rpm 3600 rpm 3000 rpm 3000 rpm
Idle running speed ² 3690 rpm 3690 rpm 3690 rpm 3120 rpm 2900 rpm
Valve clearance (engine cold) 0,2 mm 0,2 mm 0,2 mm 0,2 mm 0,16 - 0,20 mm
Cylinder head nut torque 30-33 Nm 30-33 Nm 30-33 Nm 42 Nm 58,8 - 63,7 Nm
Compression ratio 20:1 20:1 20:1 23:1 --
Lubrication oil capacity 1,25 l 1,25 l 1,25 l 2,8 l 1,3 l
Fuel consumption ³ approx 0,42- 1,12
l
approx. 0,42- 1,12
l
approx. 0,42- 1,12
l
approx. 0,5-1,4 l approx. 0,42 -
1,12 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
10-12 l/min 10-12 l/min 16-28 l/min 16-28 l/min --
Permissible max. permanent tilt of engine a) 25° across the longitudinal axis
b) 20° in the longitudinal direction
Recommend starter battery size 12 V 28 Ah
equivalent
12 V 28 Ah
equivalent
12 V 36 Ah
equivalent
12 V 28 Ah
equivalent
12 V 28 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25 mm² 25 mm² 25 mm² 25 mm² 25 mm²
Max. exhaust back pressure 9,3 kPa
93 Millibar
9,3 kPa
93 Millibar²
9,3 kPa
93 Millibar
9,3 kPa
93 Millibar
--
Panda 6500
Panda 7 mini
Panda 8000
Panda 8 mini
Panda 9000 Panda 10000
Panda 9 mini
Panda 12000
Type Z482 Z482 D722 Z602 D722
Governor MIni VCS VCS mechanic VCS VCS
Automatic start booster no yes no yes yes
Cylinder 22323
Bore 67 mm 67 mm 67 mm 72 mm 67 mm
Stroke 68 mm 68 mm 68 mm 73,6 mm 68 mm
Stroke volume 479 cm³ 479 cm³ 719 cm³ 599 cm³ 719 cm³
