Fischer Panda Panda 4K PMS - Page 152

Tables
Seite/Page 152 - Kaptitel/Chapter 9: Tables 9.2.16
² progressive speed by VCS
³ 0,35 l/kW electrical power, the randomized values between 30 % and 80 %
of the rated speed
Fig. 9.1-6: Technical data
Stroke volume 898 cm³ 1123 cm³ 1498 cm³ 2197 cm³ 2434 cm³
Max. power (DIN 6271-NB) at 3000 rpm 17,5 kW 18,7 kW 23,3 kW 20,1 kW 31,1 kW
Rated speed 1500 rpm 1500 rpm 1500 rpm 1500 rpm 1500 rpm
Idle running speed ² 1500 rpm 1500 rpm 1800 rpm 1500 rpm 1800 rpm
Valve clearance (engine cold) 0,145 - 0,185 mm 0,145 - 0,185 mm 0,2 mm 0,2 mm 0,18 - 0,22 mm
Cylinder head nut torque 63,7 - 68,6 Nm 63,7 - 68,6 Nm 68 Nm 68 Nm 93,1 - 98 Nm
Compression ratio 23:1 23:1 22:1 22:1
Lubrication oil capacity 5,1 l 5,1 l 6,0 l 9,5 l 9,5 l
Fuel consumption ³ 0,7 - 1,8 l 0,84 - 2,24 l ca. 1,20-3,36 l ca. 1,8-4,9 l approx. 1,95 -
5,2 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
6-28 l/min 28-40 l/min 28-40 l/min 28-40 l/min 40-50 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 65 Ah
equivalent
12 V 65 Ah
equivalent
12 V 70 Ah
equivalent
12 V 120 Ah
equivalent
12 V 136 Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25 mm² 25 mm² 25 mm² 70 mm² 70 mm²
Max. exhaust back pressure 10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
Panda 7,5-4 Panda 9-4 Panda 12-4 Panda 17-4 Panda 22-4
Panda 30/4 Panda 30/4 Panda 40/4 Panda 50/4 Panda 70/4
Type Mitsubishi S-DTS V3600 V3600 V3800 DI-T BF4M 1013EC
Governor VCS VCS VCS mechanic + GAC VCS
Automatic start booster no no no no no
Cylinder 44444
Bore 94 mm 98 mm 98 mm 100 mm 108 mm
Stroke 120 mm 120 mm 120 mm 120 mm 130 mm
Stroke volume 3331 cm³ 3620 cm³ 3620 cm³ 3769 cm³ 4764 cm³
Max. power (DIN 6271-NB) at 3000 rpm 45,8 kW 58,8 kW 62,0 kW 85,0 kW
Rated speed 1500 rpm 1500 rpm 1500 rpm 1500 rpm 1500 rpm
Idle running speed ² 1500 rpm 1800 rpm 2800 rpm 1800 rpm 1800 rpm
Valve clearance (engine cold) 0,25 mm 0,2 mm 0,2 mm 0,2 mm inlet 0,3
+ 0,1
mm /
outlet 0,5
+ 0,1
mm
Cylinder head nut torque 118Nm 68Nm 68Nm 68Nm
Compression ratio 20.5:1 22,6:1 22,6:1 19,0:1 17,6:1
Lubrication oil capacity 10,0 l 13,2 l 13,2 l 13,2 l 14,0 l
Fuel consumption ³ approx. 3,15-8,4 l approx. 3,15-8,4 l approx. 3,78-
10,1 l
approx. 4,2-11,2 l approx. 6,5-17,3 l
Oil consumption max. 1 % of fuel consumption
Oil specification API CF4 (SAE30) API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
40-50 l/min 40-50 l/min 40-50 l/min 40-50 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12 V 136 Ah
equivalent
12 V 136 Ah
equivalent
12 V 136 Ah
equivalent
12 V 136 Ah
equivalent
