C6.1.6/0513-0515/G 37
LABEL DESCRIPTION ZXME Level ZXLE Level ZXDE Level
C08 Setpoint offset - 0-NV L2 0-NV L2 0-NV L2
C09 Ambient temperature operature setpoint °C -20 L2 -20 L2 -20 L2
C10 pressure/temperature operation for ambient differential bar 1.0 L2 1.0 L2 1.0 L2
C11 Ambient temperature recover differential °C 5.0 L2 5.0 L2 5.0 L2
5.5.3 Low Ambient Operation
C12 Ambient temperature required to initiate low ambient on time °C -10 L2 -10 L2 -10 L2
C13 Temperature/pressure to end low ambient timer and resume normal operation bar 10 L2 10 L2 10 L2
C14 Low ambient minimum on time sec 10 L2 10 L2 10 L2
C15 Pressure to end low ambient timer and shut off the compressor bar 0.2 L2 0.2 L2 0.3 L2
5.3.2 Compressor Digital Scroll Operation Signal
C16 Digital compressor setpoint bar 3.3 L1
C17 Proporational band for compressor regulation bar 2.0 L1
C18 Band offset for compressor regulation bar 0.0 L2
C20 Start up time: interval with digital valve before start regulation sec 10.0 L2
C21 Cycle time for digital compressor sec 10.0 L1
C22 Safety value for PI regulator (in case of probe error) % 50.0 L2
C23 Number of active compressor(s) when probe error - 1.0 L2
C24 Minimum capacity for digital compressor % 20.0 L1
C25 Maximum capacity for digital compressor % 100.0 L1
C38 Compressor regulation control signal - 0-Pressure L2 0-Pressure L2 0-Pressure L2
Compressor Safety
D01 Output delay at start up sec 5 L2 5 L2 5 L2
5.3.1 Compressor Operation with Faulty Suction Probe
D02 Compressor On time with faulty probe min 5 L2 5 L2 5 L2
D03 Compressor Off time with faulty probe min 3 L2 3 L2 3 L2
D04 Minimim time between two starts (same compressor) min 4 L2 4 L2 4 L2
D05 Delay between compressor switch-off and start-up (same compressor) sec 120 L2 120 L2 120 L2
D13 Low suction pressure error signal enabling - 1-YES L2 1-YES L2 1-YES L2
5.5.2 Discharge Pressure Protection
D14 Minimum time of compressor off with high pressure switch protection min 5 L2 5 V 5 L2
D15 Number of high pressure switch activations before compressor lock - 7 L2 7 V 7 L2
5.4.2 Bump Start (only for ON/OFF compressor)
D16 Bump start enable - 0-NO L2 0-NO L2
D17 Bump start ambient threshold °C 0.0 L2 0.0 L2
D18 Compressor stop time for next bump start hour 1:00 L2 1:00 L2
D19 Compressor on time during bump function sec 2 L2 2 L2
D20 Compressor off time during bump function sec 15 L2 15 L2
D21 Number of cycles during bump start - 3 L2 3 L2
5.4.1 Ambient Based Suction Pressure Offset
