FISCHER [CF] EASY - Page 43

C6.1.6/0513-0515/G 38
LABEL DESCRIPTION ZXME Level ZXLE Level ZXDE Level
5.5.4 Discharge Line Temperature Protection
D22 DLT alarm temperature to stop compressor °C 130.0 L2 130.0 L2 130.0 L2
D23 DLT alarm recover temperature to turn on compressor °C 90.0 L2 90.0 L2 90.0 L2
D24 DLT alarm activation delay sec 30 L2 30 L2 30 L2
D25 Compressor minimum off time for DLT alarm min 5 L2 5 L2 5 L2
D26 Number of activations of DLT in a hour to stop compressor - 10 L2 10 L2 10 L2
D27 Time to ignore low DLT sensor error at startup min 5 L2 5 L2 5 L2
D28 Minimum time of compressor off with low pressure switch protection min 3 L2 3 L2 3 L2
5.6.3 Fan Modulation Setpoints Based on Compressor Envelope Maps
E01 Condenser fan motor modulation type - 2-Modulated fan L2 2-Modulated fan L2 2-Modulated fan L2
E38 Fan setpoint modulation enabling 0-NO L2 0-NO L2 0-NO L2
E39 Condenser setpoint when fan setpoint modulation is disabled °C 35.0 L1 35.0 L1 35.0 L1
5.6.2 Minimum Condensing Setpoint
E40 Minimum condenser setpoint °C 10.0 L2 10.0 L2 10.0 L2
5.6.3 High Ambient Temperature Override
E41 High ambient fan motor override enabled 1-YES L2 1-YES L2 1-YES L2
E42 High ambient fan motor override differential °C 5.0 L2 5.0 L2 5.0 L2
5.6.3 Discharge Line Temperature Override
E43 High DLT fan motor override enabled 1-YES L2 1-YES L2 1-YES L2
E44 High DLT fan motor override point for fan °C 100.0 L2 100.0 L2 100.0 L2
5.6.3 Variable Fan Speed Control
E46 Regulation band of variable fan °C 10.0 L1 10.0 L1 10.0 L1
E48 Fan full speed duration at fan startup sec 10 L2 10 L2 10 L2
E49 Fan minimum on time sec 20 L2 20 L2 20 L2
E50 Fan minimum off time sec 20 L2 20 L2 20 L2
5.6.3 Fixed Fan Cycling
5.6.11 Condenser Mid-Coil Temperature Sensor With Ambient Sensor Present
E55 Fan control with ambient sensor - Min ambient °C 0.0 L2 0.0 L2 0.0 L2
E56 Fan control with ambient sensor - Max ambient °C 20.0 L2 20.0 L2 20.0 L2
E57 Fan speed control with ambient sensor % 60.0 L2 60.0 L2 60.0 L2
5.5.7 High Condensing Warning
E58 Condenser temperature/pressure threshold for high alarm bar 27 L2 27 L2 27.8 L2
E59 High condenser temperature alarm delay min 0 L2 0 L2 0 L2
E60 High condenser temperature alarm with compressor off 1-YES L2 1-YES L2 1-YES L2
E61 Condenser temperature/pressure threshold for alarm recovery bar 23 L2 23 L2 23 L2
5.6.12 Condenser Mid-Coil Temperature Sensor with Ambient Sensor Present
