LABEL DESCRIPTION ZXME Level ZXLE Level ZXDE Level
5.7.1 Liquid Injection Control
F01 Liquid injection setpoint °C 110.0 L2 110.0 L2
F02 Max DLT temperature before full open injection °C 118.0 L2 118.0 L2
F03 Min DLT temperature before close injection °C 80.0 L2 80.0 L2
5.7.4 Injection Error Handling - DLT failure
F04 Mid-coil limp along for DLT failure - Mid-coil 1 °C 60.0 L2
F05 Mid-coil limp along for DLT failure - Mid-coil 2 °C 50.0 L2
F06 Mid-coil limp along for DLT failure - Mid-coil 3 °C 40.0 L2
F07 Mid-coil limp along for DLT failure - Mid-coil 4 °C 30.0 L2
F08 Mid-coil limp along for DLT failure - Mid-coil 5 °C 20.0 L2
F09 Mid-coil limp along for DLT failure - Valve opening 1 % 100 L2
F10 Mid-coil limp along for DLT failure - Valve opening 2 % 80 L2
F11 Mid-coil limp along for DLT failure - Valve opening 3 % 60 L2
F12 Mid-coil limp along for DLT failure - Valve opening 4 % 35 L2
F13 Mid-coil limp along for DLT failure - Valve opening 5 % 15 L2
5.7.4 Injection Error Handling - DLT failure and Mid-Coil failure
F14 Ambient limp along for DLT and mid-coil failure - Temperature 1 °C 30.0 L2
F15 Ambient limp along for DLT and mid-coil failure - Temperature 2 °C 20.0 L2
F16 Ambient limp along for DLT and mid-coil failure - Valve opening 1 % 80 L2
F17 Ambient limp along for DLT and mid-coil failure - Valve opening 2 % 35 L2
5.7.6 Injection Initial Opening Settings
F18 EVI EXV Initial opening – Ambient 1 °C 35.0 L2
F19 EVI EXV Initial opening – Ambient 2 °C 30.0 L2
F20 EVI EXV Initial opening – Ambient 3 °C 25.0 L2
F21 EVI EXV Initial opening – Ambient 4 °C 15.0 L2
F22 EVI EXV Initial opening – Valve opening 1 % 60 L2
F23 EVI EXV Initial opening – Valve opening 2 % 40 L2
F24 EVI EXV Initial opening – Valve opening 3 % 30 L2
F25 EVI EXV Initial opening – Valve opening 4 % 20 L2
F26 EVI EXV Initial opening – Valve opening 5 % 10 L2
5.7.6 Injection Initial Opening Settings - if Ambient and Mid-Coil sensor failure
F27 EVI EXV Initial opening with sensor failure % 40 L2
5.7.7 Vapour Injection Mode
F28 Differential between the vapour inlet and the vapour outlet temperature for R404A °C 5.0 L2
F29 Differential between the vapour inlet and the vapour outlet temperature for R507 °C 5.0 L2
F31 Differential between the vapour inlet and the vapour outlet temperature for R22 °C 5.0 L2
F32 Differential between the vapour inlet and the vapour outlet temperature for R407C °C 10.0 L2
F33 Differential between the vapour inlet and the vapour outlet temperature for R407A °C 10.0 L2
