FISCHER [CF] EASY - Page 45

C6.1.6/0513-0515/G 40
LABEL DESCRIPTION ZXME Level ZXLE Level ZXDE Level
5.7.7 Vapour Injection Mode (Cont'd)
F34 Differential between the vapour inlet and the vapour outlet temperature for R407F °C 10.0 L2
F35 Differential between the vapour inlet and the vapour outlet temperature for N40 °C 10.0 L2
F36 Differential between the vapour inlet and the vapour outlet temperature for DR33 °C 10.0 L2
F38 Max DLT temperature before changing from vapour to liquid injection control °C 110.0 L2
F39 Differential before resuming vapour injection °C 15.0 L2
5.7.9 EVI System Checks
F40 Max open EXV warning time min 2 L2
F41 Delta between setpoint and shortage of refrigerant error during max open warning °C 8.0 L2
5.7.10 Constant Liquid Temperature Mode for low Ambient EVI Injection
F42 Constant liquid temperature mode enabled for low ambient EVI injection - 0-NO L2
F43 Constant liquid temperature setpoint °C 0.0 L2
F44 Ambient temperature setpoint for constant liquid temperature mode °C -20.0 L2
8.0 Low Side Control
G01 Case temperature probe selection - 0-NU L2 0-NU L2 0-NU L2
G02 Case temperature setpoint °C 2.0 L2 2.0 L2 2.0 L2
G03 Case temperature differential °C 1.0 L2 1.0 L2 1.0 L2
G04 Case temperature low range °C -10.0 L2 -10.0 L2 -10.0 L2
G05 Case temperature high range °C 15.0 L2 15.0 L2 15.0 L2
8.0 Low Side Control
G06 Case probe failure limp along on time min 2 L2 2 L2 2 L2
G07 Case probe failure limp along off time min 1 L2 1 L2 1 L2
G08 Compressor and fan status when open door 0-NO L2 0-NO L2 0-NO L2
G09 Regulation with door open 1-YES L2 1-YES L2 1-YES L2
G10 Liquid line solenoid control V 0-Compressor L2 0-Compressor L2 0-Compressor L2
G11 Maximum pump down time min 3 L2 3 L2 3 L2
G56 Use the liquid line solenoid - 0-NO L2 0-NO l2 0-NO l2
5.5.9 Over Current Protection
H01 Current sensing 1 enabled - 1-YES L2 1-YES L2 1-YES L2
H02 Current sensing 2 enabled - 1-YES L2 1-YES L2 1-YES L2
H06 Voltage and current protection enabled - 1-YES L2 1-YES L2 1-YES L2
H07 Maximum continous current limit A 15 L2 15 L2 15 L2
H08 Voltage/current sening trip minimum off time min 5 L2 5 L2 5 L2
H09 Adjustable current limit before trip A 12 L2 12 L2 12.5 L2
H10 Ignore current sensing duration at startup duration sec 3 L2 3 L2 3 L2
H11 Over current trips before lockout 5 L2 5 L2 5 L2
H12 Loss of phase trips number before lockout 5 L2 5 L2 5 L2
H19 Generate warning or shut the regulation when phase imbalance - 1-Off the unit L2 1-Off the unit L2 1-Off the unit L2
H20 Missing current duration before trip sec 10 L2 10 L2 10 L2
