LABEL DESCRIPTION ZXME Level ZXLE Level ZXDE Level
5.5.20 Floodback Control
I01 Crankcase heater max ambient °C 10.0 L2 10.0 L2 10.0 L2
I02 Minimum time the compressor is off before turning the crancase heater on min 5 L2 5 L2 5 L2
N01 Current minute Set up during commissioning L1 Set up during commissioning L1 Set up during commissioning L1
N02 Current hour Set up during commissioning L1 Set up during commissioning L1 Set up during commissioning L1
N03 Day of month Set up during commissioning L1 Set up during commissioning L1 Set up during commissioning L1
N04 Month Set up during commissioning L1 Set up during commissioning L1 Set up during commissioning L1
N05 Year Set up during commissioning L1 Set up during commissioning L1 Set up during commissioning L1
P01 Compressor setpoint hysteresis in energy saving mode bar 0 L2 0 L2 0 L2
P02 Condenser setpoint hysteresis in energy saving mode °C 0 L2 0 L2 0 L2
R01 Digital input 1 function 0-Not used L2 0-Not used L2 0-Not used L2
R02 Digital input 1 polarity 1-CL L2 1-CL L2 1-CL L2
R03 Activation delay for digital input 1 min 0 L2 0 L2 0 L2
R07 Digital input 3 function 0-Not used L2 0-Not used L2 0-Not used L2
R08 Digital input 3 polarity 1-CL L2 1-CL L2 1-CL L2
R09 Activation delay for digital input 3 min 0 L2 0 L2 0 L2
S01 Alarm contact activation in a warning, alarm, lockout 1-ALARM L2 1-ALARM V 1-ALARM L2
S02 Alarm relay deactivation 1-YES L2 1-YES V 1-YES L2
S03 Buzzer enabled 0-NO L2 0-NO V 0-NO L2
S05 Relay output 2 configuration 0-Not used L2 0-Not used L2 0-Not used L2
S07 Relay output 4 configuration 0-Not used L2 0-Not used L2 0-Not used L2
S08 Relay output 5 configuration 9-Alarm L2 9-Alarm L2 9-Alarm L2
S13 Output 2 polarity 0-CL L2 0-CL L2 0-CL L2
T01 Serial address 1 L2 1 L2 1 L2
T02 Reset key configuration 1-rSt L2 1-rSt L2 1-rSt L2
T06 P1 visualization L2 L2 L2
T07 P2 visualization L2 L2 L2
T08 P3 visualization L2 L2 L2
T09 P4 visualization L2 L2 L2
T10 P5 visualization L2 L2 L2
T11 P6 visualization L2 L2 L2
T12 P7 visualization L2 L2 L2
T13 Firmware release: day L2 L2 L2
T14 Firmware release: month L2 L2 L2
T15 Firmware release: year L2 L2 L2
T16 Firmware release code L2 L2 L2
T17 EEPROM map identification 6 L2 6 L2 6 L2
T18 Enter into PR2 level L1 L1 L1
L2 L2 L2
BIT CONFIGURATION
