10
INSTALLATION HEIGHT
HEIGHT DIMENSIONS MM
A Ducted installation
z
Minimum height
z
Maximum height
636
1035
B Height top of cooktop to base of product
z
Electric cooktop
z
Gas cooktop
min 600 – max 750
min 650 – max 750
This rangehood must be installed no lower than the minimum height indicated in the table
above. Minimum installation height may be greater if required by the cooktop, refer to your
cooktop installation instructions.
Installation at the minimum height will improve the efficiency of capturing cooking odours,
grease and smoke. Installation above the minimum height is the users preference, it is not
recommended to install above the maximum height indicated in the table above.
a
b
