Fisher 1032 - Parts Kits

Type 1032
12
Parts Kits
Repair Kits for Rack-and-Pinion Rotary Actuators
PART NUMBER
MODEL NUMBER
Nitrile Seals
(Full Spare Parts)
Fluoroelastomer
Seals Only
45
70
130
185
280
425A
680A
1125
1370
2585
4580
R1032X00212
R1032X00222
R1032X00232
R1032X00242
R1032X00252
R1032X00262
R1032X00272
R1032X00282
R1032X00292
R1032X00302
R1032X00312
R1032X00412
R1032X00422
R1032X00432
R1032X00442
R1032X00452
R1032X00462
R1032X00472
R1032X00482
R1032X00492
R1032X00502
R1032X00512
Parts Included in Kit
Key Description Quantity in Kit
5
11
12
13
14
15
16
17
18
19
20
22
22
23
26
Safety key
Sealing washer
Piston O-ring
End cap O-ring
Upper pinion bearing
Lower pinion bearing
Piston bearing
O-ring
O-ring
Thrust bearing
Thrust bearing
Sealing washer
(Spring return with
chamfer hole only)
Sealing washer
(Spring return without
chamfer hole only)
Snap ring
O-ring
2
2
2
2
1
1
2
1
1
2
2
2
2
2
1
2
---
2
2
2
---
---
---
1
1
---
---
2
2
2
---
2
Retractor Rod Kits
PART NUMBER
MODEL NUMBER
2 Retractor Rods
(1)
Provided
Per Each Number Ordered
45
70
130
185
280
425A
680A
1125
1370
2585
4580
12B9219X012
12B9219X022
12B9219X112
12B9219X032
12B9219X042
12B9219X052
12B9219X062
12B9219X072
12B9219X082
12B9219X092
12B9219X102
1. Retractor rods are required with disassembly or assembly of spring return actuators. Refer to the Maintenance procedures in this manual.
