Fisher 1032 - Parts List

Type 1032
13
Parts List
Refer to the tables in figures 9 and 10 for the key num-
ber and part description for each part required. Use
this information when ordering parts.
Key
Number
Part
Description
Qty
Req’d
Key
Number
Part
Description
Qry
Req’d
1
2
3
4
5
(1)
9
10
11
(1,2)
12
(1,2)
13
(1,2)
Body
Pinion
Piston
End Cap
Safety Key
Travel Stop Adjustment Bolt
Travel Stop Lock Nut
Sealing Washer
Piston O-Ring
End Cap O-Ring
1
1
2
2
2
2
2
2
2
2
14
(1)
15
(1)
16
(1)
17
(1,2)
18
(1,2)
19
(1)
20
(1)
23
(1)
24
26
(1,2)
Upper Pinion Bearing
Lower Pinion Bearing
Piston Bearing
O-Ring
O-Ring
Thrust Bearing
Thrust Washer
Snap Ring
Position Indicator (optional)
O-Ring
1
1
2
1
1
2
2
1
1
2
1. These parts are in spare parts kit.
2. These parts are in fluoroelastomer seal kit.
Figure 10. Type 1032 Double-Acting Actuator
33B0251-A
A5828-1 / IL
