Type 1032
14
Key
Number
Part
Description
Qty
Req’d
Key
Number
Part
Description
Qty
Req’d
1
2
3
4
5
(1)
6
7
8
9
10
11
(1,2)
12
(1,2)
13
(1,2)
Body
Pinion
Piston
End
Cap
Safety Key
Spring
Spring
Retractor Spring Seat
Travel Stop Adjustment Bolt
Travel Stop Lock Nut
Sealing Washer
Piston O-Ring
End Cap O-Ring
1
1
2
2
2
2
2
2
2
2
2
2
2
14
(1)
15
(1)
16
(1)
17
(1,2)
18
(1,2)
19
(1)
20
(1)
21
22
(1,2)
23
(1)
24
26
(1,2)
Upper Pinion Bearing
Lower Pinion Bearing
Piston Bearing
O-Ring
O-Ring
Thrust Bearing
Thrust Washer
Cap Screw
Sealing Washer
Snap Ring
Position Indicator (Optional)
O-Ring
1
1
2
1
1
2
2
2
2
1
1
2
1. These parts are in spare parts kit.
2. These parts are in fluoroelastomer seal kit.
Figure
11. Spring-Return Actuator
33B0252-A
A5829-1 / IL
