Instruction Manual
D102178X012
V260 Valve
July 2017
14
Parts List
Note
Contact your Emerson sales office
or Local Business Partner for Part
Ordering Information.
Key Description
1 Valve Body
If you need a valve body as a replacement part, order the
valve size, pressure rating, serial number, and desired
material. Contact your Emerson sales office.
2 Inlet Tailpiece
3 Body Stud
4 Bearing Plate (2 req'd)
5 Dowel Pin (8 req'd)
6 Outlet Tailpiece
7* Seal Assembly O‐Ring (1 req'd for single, 2 req'd for dual seal)
8 Wave Spring (1 req'd for single, 2 req'd for dual‐seal)
9* Outlet Seal Assembly
10 Attenuator Dome for Dual Seal
11 Ball
12* Tailpiece O‐Ring (2 req'd)
13 Dome Spacer
14* Packing Box O‐Ring
15 Dome Spacer O‐Ring
16 Packing Box Housing
Key Description
17* Inlet Seal Assembly
18* Dowel Pin (4 req'd)
19 Body Hex Nut
20 Drive Shaft
21 Actuator Mounting Cap Screw (4 req'd)
22 Packing Housing Stud, Steel
23 Packing Housing Nut, Steel
24* Shaft Thrust Washer
25 Pipe Plug (not shown)
26 Flow Arrow
27 Drive Screw, for nameplate
28 Attenuator Dome for Single Seal
29* Trunnion Bearing (2 req'd)
30* Ball Thrust Washer (2 req'd)
32* Shaft Bearing
33 Pin, Attenuator Dome (not shown)
34 Nameplate (not shown)
36 Drive Screw (not shown)
37 Washer (not shown)
100 Packing Stud (2 req'd for NPS 8-12, 4 req'd for NPS 16-24)
101 Packing Nut (2 req'd for NPS 8-12, 4 req'd for NPS 16-24)
102 Packing Flange
105* Packing Set
ENVIRO-SEAL
PTFE/Carbon-Filled PTFE
Standard
PTFE/Carbon Filled PTFE
106 Anti‐Extrusion Ring, PTFE
107 Packing Box Ring
116 Clamp (grounding strap assembly)
117 Grounding Strap Assembly
*Recommended spare parts
