FLAMMA FX200 - Back Panel Connectivity Ports; Audio and Control Input;Output Jacks; MIDI, USB, Power, and Switch Ports

www.flammainnovation.comShenzhenFlammaInnovationCo.,Ltd
05
BackPanel
02 03 04 05 06 07 08 09 10
11 12
1301
AUXIN：1/8”stereoaudioinputjack,forconnectingtoexternalaudiodevice.
EXP2：1/4”stereoaudioinputjack,connecttoexternalexpressionpedal(Notes:pleaseuse1/4”TRS
cable.)
INPUT：1/4”monoaudioinputjack,connecttoguitarortotheoutputofanotherpedal.
SEND：1/4”monoaudiooutputjackofFXLOOP,connecttotheinputjackofexternalpedal,orconnect
totheinputofamplifierwhenusingfour-cablemethod.
RETURN：1/4”monoaudioinputjackoftheFXLOOP,connecttotheoutputjackofanexternalpedal,or
connecttotheSENDofanamplifierwhenusingfour-cablemethod.
OUTPUT：1/4”stereoaudiooutputjackforunbalancedsignal,pleaseconnecttoL(MONO)formono
audiosetup.
PHONES：1/8”stereoheadphoneoutput.
GND/LIFT:GroundandliftswitchforXLRoutput.
XLROUT：XLRstereoaudiooutputforbalancedsignal,pleaseconnecttoL(MONO)formonosetup.
MIDIIN/MIDIOUT：5PINMIDIport,canbesettoMIDIINorMIDIOUT.
USB：Type-CUSBport,forconnecttocomputerforpresetmanagement,importIRfile,firmwareupdate
orusetheunitasanaudiointerface.
DCIN：Powerport,recommendtousetheoriginalpowersupplyforit.
PowerSwitch:Toggleon/offtheunit.
