FLETCHER 2200 - INTRODUCTION; Product Warranty

3
INTRODUCTION
The Fletcher 2200™ Professional Mat Cutter is designed with the professional framer in mind and has evolved from the
proven concepts of the Fletcher 2000
®
and Fletcher 2100
®
and incorporates many suggestions from the users of
Fletcher-Terry framing products. Particular attention has been devoted to ergonomic design to provide comfort and ease
of use. The Fletcher 2200 is available in imperial (40”, 48” and 60”) and metric (1.0m, 1.2m and 1.5m) versions.
The Cutting Head incorporates both bevel and straight cutting with comfort designed into both pivots. The straight
(sizing) side uses a blade and magazine that cuts materials such as foamboard and gatorfoam
®
up to a nominal 1/2”
(12mm) thick. Both magazines permit blade changing away from the Cutting Head minimizing exposure to the hazard of
handling sharp blades. A unique Sight Gage on the Cutting Head provides precise control of over/under cuts when
using pencil lines on the back of the mat.
The Cutting Head is fitted to a polished Shaft minimizing wear and “hooking”. Adjustments are available so the framer
can maintain the close fit in spite of heavy usage.
The usefulness of the popular Locator Pin has been improved by adding holes in the Mat Guide Slide to provide mat
borders from 1-1/2” to 8” in 1/2” increments on the imperial version and 30mm to 210mm in 10mm increments on the
metric version.
Options include: Measuring Stops assure minimum over cuts and under cuts; Clamp Lifters allow both hands to be free
to place the mat in position; the Right Squaring Arm attaches to the base providing a rigid, accurate means of sizing
mats; the Angle Mat Guide attaches to the Mat Guide creating a means of cutting angles other than 90 degrees in an
opening and a Base Plate Extension permits mat borders up to 16” (405mm).
Multiple mats, V-grooves, and other creative mat designs can be easily and accurately produced on the Fletcher 2200.
Product Warranty
The Fletcher-Terry Company warrants the Fletcher 2200 to be free from defects in parts and
workmanship for (2) two years from the date of purchase. The Fletcher-Terry Company warrants
that it will repair or replace any such defective machine or replace parts, providing the machine
has been under normal use and service and the defective part or machine is returned to The
Fletcher-Terry Company at the purchaser’s expense. The Fletcher-Terry Company must autho-
rize the return in writing. Proof of purchase must be submitted to validate warranty coverage.
The warranty is in lieu of all other agreements and warranties expressed or implied. THE
FLETCHER-TERRY COMPANY DOES HEREBY EXPRESSLY DISCLAIM ANY WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. The Fletcher-Terry
Company does not authorize any company employee or representative to assume for it any
other liability than that set forth in this Product Warranty. The Fletcher-Terry Company shall not
be liable for any damages or losses, whether incidental or consequential or direct or indirect,
arising out of the use or abuse of this machine. In any event, THE PURCHASER’S SOLE AND
EXCLUSIVE REMEDY UNDER THIS OR ANY OTHER WARRANTY IS LIMITED TO RETURN
OF THE PURCHASE PRICE PAID FOR THIS MACHINE.
70
Ref. Pieza Descripción Cantidad
1 12-101 Montaje de la abrazadera en ángulo 1
2 12-099 Soporte de la abrazadera en ángulo 1
3 12-020 Tornillo de cabeza de cono achatado 2
4 12-027 Tuerca hexagonal 3
5 24-129 Arandela prisionera 3
6 24-130 Arandela 3
7 12-098 Abrazadera en ángulo 1
8 12-106 Montaje del brazo en escuadra 1
9 12-102 Brazo en escuadra 1
10 12-103 Soporte de passe-partout 1
11 12-578 Escala 1
12 12-024 Tornillo de cabeza achatada 2
13 12-016 Tuerca excéntrica 1
14 12-056 Tornillo de tapa del extremo 1
15 12-516 Parada del brazo en escuadra 1
16 12-350 Tirador plástico 1
17 12-514 Llave 1
CABEZAL DE CORTE
Ref. Pieza Descripción Cantidad Ref. Pieza Descripción Cantidad
1 12-572 Montaje del pivote del 10 12-537 Tornillo de tope 2
cabezal (izquierdo) 1 11 12-538 Cojinete 2
2 12-530 Resorte de extensión 2 12 12-591 Montaje del pivote del
3 12-588 Arandela de acero inoxidable 2 cabezal (derecho) 1
4 12-532 Tornillo del pivote 2 13 12-915 Tirador (derecho) 1
5 12-533 Arandela de suplemento 4 14 12-542 Montaje de la bandeja (izq.) 1
6 12-589 Empuñadura confortable(izq.) 1 15 12-102 Brazo del pivote 1
7 12-535 Tirador (izquierdo) 1 16 12-593 Montaje de la bandeja (derecho) 1
8 12-590 Tornillo de tapa del extremo 17 12-241 Tirador plástico (derecho) 1
de cabeza plana 5 18 12-242 Tachuela hexagonal 1
9 12-073 Rodamiento a rodillo 3 19 12-243 Mira 1
20 12-592 Empuñadura confortable (der.) 1
BRAZO EN ESCUADRA
19
2
3
4, 5
7
9
10
11
12
13
1
6
8
14
16
17, 18
A
A
Section A-A
15
1
2
3
4, 5, 6
7
8
9
10
11
12
13
14
15, 16, 17
12
4, 5, 6
20
