8.5 Configuration
The general configuration is set in this menu screen.
CONFIGURATION
SENSORS
FIRE/SMOKE
COMMUNICATION
START/STOP SEQUENCE
REST MODE
>
>
OK?
>
>
Sensors
The temperature sensors can be calibrated in this menu
to be better coordinated with the real situation, and a
pressure sensor is activated as a pressure guard instead
of the integrated time control.
SENSORS
SUPPLY AIR
EXTRACT AIR
OUTDOOR AIR
RETURN WATER
FILTER GUARD
>
>
OK?
>
>
The menu screen is identical for all temperature sensors
and they can be adjusted within an interval of 5 °C.
SUPPLY AIR
CALIBRATION
OK?0
If the pressure guard is activated, an external sensor must
be connected to the control card. The sensor replaces
the integrated filter time control.
FILTER GUARD
ACTIVATION
OK?OFF
Fire/Smoke
This function requires an external sensor to be connected
to the control card.
FIRE/SMOKE
MODE
OK?1
Mode Supply air fan Extract air fan
1 STOP STOP
2MAX MAX
3 STOP MAX
4 MAX STOP
Communication
Proceed to the “HOME/AWAY”submenu. This function can
be used to make the unit run on other operating settings
using an external switch.
NB! The settings have no effect unless an external switch
is connected.
The settings are entered for the AWAY selection. Speed
and temperature can be selected, plus how long after
activation the new setting should take effect.
COMMUNICATION
HOME/AWAY
OK?
