Flexit UNI 2 - Door Operation and Removal; Wall-Mounted Unit Door Handling; Door Removal Safety Warning

5
2 Operating the door
2.1 Wall-mounted unit
1. First undo the screw in the top of the door (see Fig. 3).
2. Pull the handles out and rotate to the side (see Fig. 4).
3. The door can now be opened to hang open at 180º
(see Fig. 5) or unhooked (see point 2.4).
Fig. 3
Fig. 4
Fig. 5
If the door needs to be removed
The door can be removed when it is open between 40º
and 105º. If there is limited space in front of the unit, the
lock screw on the underside of the unit can be unscrewed
temporarily (see Fig. 6). Then the door can be pushed out
sideways (see Fig. 7).
Fig. 6
Fig. 7
The door is heavy, so take care when
removing it.
!
MAX 180°
