Flexit UNI 2 - Floor-Mounted Unit Door Handling

6
M
AX 105°
2.2 Floor-mounted unit
1. Make sure that hinge stops and a door strap are fitted
(see Fig. 8, 9 and 10).
2. Undo the screw in the top (see Fig. 11).
3. Pull the handles out and rotate to the side (see Fig. 4).
4. The door can now be opened to a maximum of 105º
(se Fig. 8).
MAX. 105°
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
