Flexzilla Electric Operated, Oil-Free Portable Air Compressors
7. PRE-OPERATION CHECKLIST
Inial Set-up:
Package Contents:
1.) Air compressor
2.) Owner’s Manual
3.) Air Filter Kit (2)
- Includes pre-assembled unit consisng of male housing, female
housing, lter element, and intake tube
4.) An-Vibraon Foot Kit (4)
- Includes elastomer pad, screw, and nut
5.) Wheel Kit (2)
- Includes wheel, bolt, at washer, lock washer, and nut
5.) Hot Surface Protecon Kit (2)
- Includes plasc head cover, head cover clamp, 2 screws
Assembly:
1.) Install Foot Kit (2 Locaons)
- Lay down compressor handle side down to prevent unit from rolling
- Insert bolt through elastomer foot and through hole located in frame
- Thread nut onto bolt, lightly ghten
- Repeat at remaining locaon
- Leave compressor in this posion for step 2
2.) Install Wheel Kit (2 Locaons) (CB20100F/CB20200F models only)
- Li compressor slightly to raise wheel o ground
- Insert bolt through wheel and through hole in bracket
- Install at washer over bolt
- Install lock washer over bolt
- Thread nut onto bolt and ghten with wrench
- Repeat at remaining posion
- Tip compressor upright by using the handle
3.) Install Air Filter
CF10050F (1 Locaon)
- When facing the front of compressor, locate the thread port in
motor head along le side
- Thread lter into port, and ghten by hand securely
CB20100F/CB20200F (2 Locaons)
- When facing the back of compressor, locate the thread ports near
the top of the motor head behind the handle
- Thread lter into port, and ghten by hand securely
4.) Install Hot Surface Protecon Kit (2 Locaons)
- When facing the rear of the compressor, place plasc head cover
over the cylinder head
- Note: The screw holes are located near the center of the
compressor pump
- Place head cover clamp below the plasc head cover
- Insert the 2 screws and ghten with PH2 screw driver securely
Screw
Elastomer Foot
Bolt
FOOT KIT DIAGRAM
Wheel
Flat Washer
Lock Washer
Nut
Bolt
WHEEL KIT DIAGRAM
(CB20100F/CB20200F)
AIR FILTER LOCATION
(CF10050F)
AIR FILTER LOCATION
(CB20100F/CB20200F)
