FLIGHTORY LARK - Slajd 31: Tail assembly

Tail assembly
USER MANUAL
31
Prepare the tail boom. Cut a carbon tube with a diameter of 12mm to a length
of 430mm. Before gluing the tail, you can make sure that the tail boom has
"fully entered" the designated slots. Correctly, the marked distance between the
fuselage and the tail should be 173mm.
173mm
